Inline 3D Metrology for Precision Manufacturing
Nanometer precision. millidegree alignment. Inline speed. Bridging the gap between off-line quality control and inline automation — so automated tools can align, verify and scale throughput at line-speed.
Advanced Inline 3D Micro-Metrology
Lab-grade nanometer accuracy. Production-line speed.
Nanometer Vertical Resolution
Capture nanometer-scale surface topography, layer thickness and roughness for photonics, semiconductor packaging and precision optics.
Inline 3D Metrology
SX3D combines advanced 3D perception, Physics-Informed Intelligence and industrial automation to deliver reliable measurement, alignment and positioning results for demanding manufacturing applications.
About SculpX Imaging
SculpX Imaging develops inline metrology solutions for OEMs, machine builders and system integrators. By combining advanced 3D perception, Physics-Informed Intelligence and industrial automation, we transform complex image data into reliable measurement, alignment and positioning results for demanding manufacturing applications.
Inline 3D Metrology
SX3D combines advanced 3D perception, metrology, alignment intelligence and machine integration into a single industrial platform designed for OEMs, machine builders and system integrators.
3D Perception
Capture depth, geometry and surface information from complex industrial components and assemblies, creating the foundation for reliable measurement, inspection and positioning.
Alignment Intelligence
High-precision algorithmic alignment systems engineered to ensure sub-micron accuracy across high-speed automated production pipelines.
Machine Integration
Seamlessly bridge hardware and software interfaces for real-time decision-making, quality control feedback, and closed-loop manufacturing automation.
SX3D PLATFORM CONFIGURATIONS
Built on the same SX3D Vision & Metrology Platform, each configuration is optimized for different field-of-view, resolution and integration requirements.
Nanometer
Fast, high-density micro-metrology for maximum precision micro features.
Expanded FOV
Fast 3D topography of larger structures and assemblies.
Inline Integration
Cost-effective 3D inline measurement & feature alignment.
SX3D PLATFORM COMPARISON
| FEATURE | SX3D-PM HIGH RESOLUTION | SX3D-PM LARGE AREA | SX3D-UC |
|---|---|---|---|
| Application Focus | Micro Features & Maximum Precision | Larger Components & Expanded FOVs | Cost-Efficient Inline Integration |
| Primary Strength | Sub-micron lateral detail & nanometer height accuracy | High-speed coverage of larger structures with nanometer Z-precision | Compact form factor for machine integration & inline checks |
| Measurement Capability | Fast, high-density micro-metrology | Fast 3D topography of larger structures & assemblies | Cost-effective 3D inline measurement & feature alignment |
| Field of View | up to 6 × 6 mm² | up to 24 × 26 mm² | up to 50 mm² |
| Lateral Resolution (X,Y) | down to 0.12 µm | down to 4 µm | down to 6.25 µm |
| Vertical Resolution (Z) | down to 0.01 µm (10 nm) | down to 0.01 µm (10 nm) | down to 2.6 µm |
